Colored Power-Generating Insulated Panel

Integrated BIPV Wall System for Modern Green Buildings

With China’s “Dual-Carbon” goals accelerating, the government has released a series of policies encouraging the development of Building-Integrated Photovoltaics (BIPV) and promoting low-carbon energy use in buildings. The demand for high-performance, multifunctional, and sustainable photovoltaic building materials continues to rise.

Responding to this trend, HEADSTREAM, together with Akcome, has jointly developed the Colored Power-Generating Insulated Panel, an exemplary product that combines building energy efficiency with green power generation.

Product Overview: Colored Power-Generating Insulated Panel

This innovative cladding material integrates a fireproof insulation layer, colored photovoltaic module, and decorative surface into a single panel.

It offers excellent thermal performance while converting sunlight into clean electricity, meeting modern architectural needs for functionality, energy efficiency, sustainability, and aesthetics.

Part 1. Outstanding Thermal Performance

• Thermal conductivity as low as 0.31 W/(㎡·K)

• Thermal resistance up to 3.27 (㎡·K/W)

• Suitable for multiple climate zones

The panel effectively reduces energy transfer and helps buildings achieve ultra-low energy consumption standards.

Part 2. Rich and Customizable Aesthetic Options

• Available in black, blue, gold, silver, copper, and more.

• Customized colors can be produced to match architectural façade designs.


  The appearance integrates seamlessly with traditional curtain wall systems while maintaining full power-generation capability.

Part 3. Significant Economic Benefits

Using a back-mounted triple-junction junction box, the system connects through pre-reserved openings:

Solar Energy → DC → Inverter → AC → Distribution or Energy Storage

As both a insulated building envelope and a power-generation system, the panel transforms the wall into a vertical energy-producing asset:

     Short payback period: 6–8 years

     Long-term energy income

     Eligible for green electricity subsidies and carbon credit revenue

     Improves green building certification scores

Effectively turning the building façade into a clean-energy power station.

Part 4. Class A Fire Safety

• Core made of hydrophobic fireproof rock wool

• Certified Class A fire resistance

• Complies with GB50016-2023 fire safety requirements for exterior wall materials

• Ensuring excellent fire, moisture, and weather resistance.

Part 5. Reliable Product Performance

• High-strength polymer facings with excellent bending resistance

• Much lighter than glass-based BIPV systems

• Easy installation with strong structural adaptability

• Simple, stable wiring design and low maintenance

• Suitable for both new construction and renovation projects.

Part 6. Wide Application Scenarios

Ideal for:

• Industrial plants

• Commercial complexes

• Public buildings

• Premium residential buildings

• Transportation hubs

• Data centers, hospitals, and sites requiring uninterrupted power

As a vertical power-generation unit, it requires no additional land and complements roof PV systems, significantly expanding the building’s usable power-generating area.

Conclusion: Redefining the Power-Generating Building Façade

In the era of green development and strict carbon standards, HEADSTREAM’s Colored Power-Generating Insulated Panel breaks the limitations of traditional materials:

      Energy-efficient insulation

      Class A fire resistance

      Modern aesthetics

      On-site green electricity generation

With its highly integrated design, it simultaneously fulfills the needs of thermal protection, decoration, fire safety, and energy generation, bringing long-term economic value to owners and creating tangible environmental benefits.
